Digital Area Gas Alarm

ZONAL DEVICES

In healthcare facilities, the integrity and reliability of the medical gas supply is paramount to patient safety. The Area Gas Alarm is designed to monitor the pipeline pressure within the facility. Securely housed in a sturdy enclosure to prevent unauthorised access; and a user-friendly interface for operating, re-configuration or servicing by authorised medical gas personnel.

Designed with real-time pressure readout on the display panel and programmed to raise alerts, both visual and auditory, when abnormal pressure is detected, as per the recommendations of ISO 7396-1 and HTM 02-01 standards.

<  Previous - Analogue Area Gas Alarm  |

|  Next - Area Valve Service Unit  > (Coming Soon)

ACE Medical Gas Alarms are designed for continuous monitoring of pipeline pressure and provide immediate alarm indication in case of abnormal pressure, in accordance with ISO 7396-1.
  • Quick Installation Factory-configured unit for ready installation.
  • User-Friendly Interface Intuitive interface allows for easy setup and reconfiguration of alarm thresholds if needed.
  • Pressure Gauges Pressure gauges provide real-time visual status of pressure levels.
  • Visual Indicators Visual alarm indication through colour-coded LEDs to provide a clear and immediate visual alert of any issues.
  • Auditory Indicators An audible alarm is triggered when gas levels deviate from the set thresholds or in case of a system fault.
  • Continuous Monitoring The system is designed to provide continuous, 24/7 monitoring of gas levels and system performance.

Please refer to the User Manual for more details.
  •
The alarm is triggered under the following conditions:
  1. Pressure deviation beyond 20% of the nominal distribution pressure
  2. Faulty pressure sensors


  • TEST Button     To check the operational status of visual and auditory indicators, press once and observe for any non-functioning indicators.


  • MUTE Button     To acknowledge alarm, press once.



  1. The alarm is automatically restored in 15 minutes in case of an unresolved alarm.
  2. The alarm immediately resets in case of new alarm event.
  •
The unit is capable of monitoring up to 6 gas services.
  • Oxygen
  • Vacuum
  • Medical Air
  • Surgical Air
  • Nitrous Oxide
  • Carbon Dioxide



  Order Code
1 GAS
Oxygen		 AC 4311
2 Gas
Oxygen, Vacuum		 AC 4302
3 Gas
Oxygen, Air, Vacuum		 AC 4303
4 Gas
Oxygen, Nitrous Oxide, Air, Vacuum		 AC 4304
5 Gas
Oxygen, Nitrous Oxide, Air, Air 800, Vacuum		 AC 4305
6 Gas
Oxygen, Nitrous Oxide, Carbon Dioxide, Air, Air 800, Vacuum		 AC 4306
Alarm Activation
  • Abnormal Pressure ±20% of nominal distribution pressure
    as mentioned below
  • Sensor Fault Alarm with activation for open contacts

Visual & Audio signal
  • Visual Illuminated and colour-coded LED indicators
  • Audio Alarm sound

Nominal working pressure
  • 400 kPa / 58 psi
    [O2, Air-400, N2O, CO2]
  • 800 kPa / 100 psi
    [Air-800]
  • -60 kPa / -450 mmHg
    [Vac]

Power Supply
  • 230 VAC

Inlet/Outlet Connection
  • Brazing to pipeline

    ⌀12mm
    [O2, Vac, Air400, Air800, N2O, CO2]

Box Material
  • Powder coated galvanised steel



Mounting Type
  • Surface-mounted

Storage Temperature
  • -20ºC to 60ºC
Digital Area Gas Alarms are designed and manufactured in line with the requirements of
  • ISO 7396-1:2016
  • HTM 02-01



See Certificates
